Plot plan for gas station in Detroit located at Hubbard and W. Grand Boulevard

Favorite this
Plot plan for gas station in Detroit located at Hubbard and W. Grand Boulevard
Description:
Plot plan for gas station number 17 located in Detroit, Michigan. Printed on front: 'Plot plan, Detroit Station #17, S.E. cor. Hubbard & W. Grand Blvd. White Star District. Socony Vacuum Oil Company, Inc. Scale 1/8"=1'-0". Drawn 2-5-39. Note: Station dimensions from working drawings, lot size & angles from survey.'
Details
Resource ID:
na000108
Creator:
White Star Refining Co.
Subject:
White Star Refining Co.
Service stations--Michigan--Detroit
Service stations--Designs and plans
Socony Vacuum Oil Company
Petroleum industry and trade--Michigan
Photographic prints
Date Issued:
1939-02-05
Format:
1 photographic print mounted on fabric ; 5 x 7 in.
Member of:
Burton Historical Collection
Filing Location:
MS/White Star Refining Co., Box 1
Rights:
Physical rights are retained by DPL. Copyright is retained in accordance with U.S. copyright laws.
