Plot plan for gas station in Detroit located at Gratiot and Sylvester

Favorite this
Plot plan for gas station in Detroit located at Gratiot and Sylvester
Description:
Plot plan for gas station number 3 located in Detroit, Michigan. Printed on front: 'Plot plan, Detroit Station #3, S.E. cor. Gratiot & Sylvester Av. White Star District. Socony Vacuum Oil Company, Inc. Scale 1/8"=1'-0". Redrawn 8-30-39. Note: Lot dim. & angles from survey of 3-9-39, building dimensions from working plans, 2-22-39.'
Details
Resource ID:
na000099
Creator:
White Star Refining Co.
Subject:
White Star Refining Co.
Service stations--Michigan--Detroit
Service stations--Designs and plans
Socony Vacuum Oil Company
Petroleum industry and trade--Michigan
Photographic prints
Date Issued:
1939-08-30
Format:
1 photographic print mounted on fabric ; 5 x 7 in.
Member of:
Burton Historical Collection
Filing Location:
MS/White Star Refining Co., Box 1
Rights:
Physical rights are retained by DPL. Copyright is retained in accordance with U.S. copyright laws.
