Concrete test cylinders cut from diamond drill cores through completed tunnel lining, Detroit water supply system

Grab

Description

View of concrete test cylinders cut from diamond drill cores through completed tunnel lining, Detroit water supply system. Printed on front: "#33. Springwells tunnel contract section no. 4. Mark R. Hanna Co., contractor. View showng typical compression test failures of standard 6" x 12" concrete test cylinders cut from diamond drill cores taken through completed tunnel lining. Left to right: cylinder nos. 228-228A-229 top and bottom 231A-231. Oct. 22, 1928."

Details

Resource ID:: bh017097
Subject:: Drill core analysis; Detroit (Mich.). Department of Water Supply; Photographic prints
Date:: 1928-10-22
Format:: 1 photographic print ; 7.5 x 9.5 in.
Department:: Burton Historical Collection
Location:: MS/Detroit Archives. Water Board. Miscellaneous no. 2, 3 of 3, 11:3
