1932 Packard Eight automobile rear axle assembly

Grab

Description

Artist's depiction of the rear axle assembly for a 1932 Packard Eight car. Handwritten on back: "1932 Packard Eight, Ninth series, Model 901. 8 cy., 110 b.h.p., 129 1/2" whb. Chassis. Detail: Rear axle assembly. Cross section, plan view. Mechanical, folder #1."

Details

Resource ID:: na042777
Subject:: Packard automobile; Automobiles--Axles; Photographic prints
Date:: 1931-09-28
Format:: 1 photographic print mounted on fabric ; 7.5 x 9.5 in.
Department:: National Automotive History Collection
Collection:: Packard Collection
Location:: Packard, 1932
Negative Number:: 1350-C
