Plot plan for gas station in Detroit located at Grand River and Clarendon Avenue

Grab

Description

Plot plan for gas station number 9 located in Detroit, Michigan. Printed on front: 'Plot plan, Detroit Station #9, S.E. cor. Gd. River & Clarendon Ave. White Star District. Socony Vacuum Oil Company, Inc. Scale 1/8"=1'-0". Redrawn 3-26-36. Note: Lot dim. from city records, lot angles from survey, 7-13-30, station dim. from field measurements.'

Details

Creator:: White Star Refining Co.
Resource ID:: na000086
Subject:: White Star Refining Co.; Service stations--Michigan--Detroit; Service stations--Designs and plans; Socony Vacuum Oil Company; Petroleum industry and trade--Michigan; Photographic prints
Date:: 1936-03-26
Format:: 1 photographic print mounted on fabric ; 5 x 7 in.
Department:: Burton Historical Collection
Location:: MS/White Star Refining Co., Box 1
Copyright:: Physical rights are retained by DPL. Copyright is retained in accordance with U.S. copyright laws.
