Plot plan for gas station in Detroit located at Tireman and Northfield

Grab

Description

Plot plan for gas station number 22 located in Detroit, Michigan. Printed on front: 'Plot plan, Detroit Station #22, N.W. cor. Tireman & Northfield Ave. White Star District. Socony Vacuum Oil Company, Inc. Scale 1/8"=1'-0". Redrawn 4-23-36. Note: Lot dim. & angles from city records, station dim. from field measurements.'

Details

Creator:: White Star Refining Co.
Resource ID:: na000191
Subject:: White Star Refining Co.; Service stations--Michigan--Detroit; Service stations--Designs and plans; Socony Vacuum Oil Company; Petroleum industry and trade--Michigan; Photographic prints
Date:: 1936-04-23
Format:: 1 photographic print mounted on fabric ; 5 x 7 in.
Department:: Burton Historical Collection
Location:: MS/White Star Refining Co., Box 1
